DQ Series Marine Electric Equipment Diving Navigation Signal Light
Application:
They are used for the conventional powered submarine,nuclear-powered submarine to prevent collision
as the lighting signal,formation sailing signal,anchor signal.applied to dive under the water 400m.
Characteristics:
1. The shell,shell ring and cover all founded by silicon brass,have big compressive strength,can
withstand the immersion corrosion ability of the seawater,good radiation performance.
2. The material of seal is neoprene,have the function of oil-resistant,pressure-resistant,mildewproof
and antiseptic-resistant,can prolong using life-span.
3. The parts of the lamp holder is high temperature resistant,moist resistant,mildew resistant,
good insulating performance,shock resistant,good structural strength and so on.
4. Diving navigation light can endure 6Mpa pressure,can dive under the water 400m.
Standard:
CB518-2005 Diving navigation light.
Specification:
| Type | Name | Visibility | Level arc | Cable outside Diameter | Lamp Holder | Bulb | Color | Weight |
| DQ1 | Starboard light | 3n.m | 112.5° | Φ20 | B22d | 220V/120W | green | 14.6kg |
| DQ2 | Port light | 3n.m | 112.5° | red | 14.6kg |
| DQ3 | Masthead light | 6n.m | 225° | transparent | 13.1kg |
| DQ4 | Stern light | 3n.m | 135° | transparent | 14.5kg |
| DQ5 | Afterangel light | 3n.m | 10° | transparent | 18.3kg |
| DQ6 | Anchor light | 3n.m | 360° | transparent | 12.8kg |
Quality Control:
Product Range: We specialized in majority of marine equipments& technique solution.
Product Design: With strong engineer team, for all marine products, we support design, manufacture, install etc, according to your requirements. All products strictly conform to your confirmation.
Product Process: Most of products are finished in our manufacture bases, thus quality and delivery time could keep best and , also avoid some details mistake
Product Inspection: We support factory inspection and inspection/certification.
Certificates:
- Material certificates by a classification society
- Inspection protocol
- Inspection reports tank testing
- NDT reports
- Official certificates for accessories and other equipment
Advantages of our factory:
1. Control the product quality from the source
2. The main mechanical stress components should pass flaw detection to ensure the quality.
3. Adopt domestic famous brand electric device
4. Fully equipped with accessories
5. Easy installation and operation
6. Provide professional customization service
7. Reasonable price and good after-sale service
8. Manufacture according to client's rquirements
